Description

X400 Standard Features:

  • Selectable 4×4
  • EFI 400cc
  • Winch 2500lb
  • Tow Hitch
  • HD 6 ply tyres
  • Quad Bar CPD included
Specifications
Engine Single cylinder, 4 vales, 4 stroke, SOHC
Displacement 400cc
Bore x Stroke 91 x 61.5 mm
Compression Ratio 9.7:1
Fuel System E.F.I. Delphi MTO 5
Cooling Liquid Cooled & Additional oil cooler fitted (Australian market)
Start Type Electric and recoil pull star
Transmission CVTech
Power 18Hp / 6500 rpm (29.5HP)
Max Torque 22N.m / 5500 rpm
Ignition ECU
Suspension / Brakes / Tyres
Suspension Front Double A-ARM and independent
Suspension Rear Single Swing Arm Mono shock
Brakes Front Hydraulic disc
Brakes Rear Hydraulic disc
Dimensions
Product Dimensions 2100mm x 1060mm x 1170mm
Ground Clearance 250 mm
Wheelbase 1305 mm
Towing 350 kg
Carrying 35kg (front rack) / 60kg (rear rack) /140kg Total Passenger load
Wet Weight 305 kg
Fuel Capacity 11 L
Winch 2500LB
Safety
Safety Using ATV with Passenger greatly increases risk of Rollover. Speed should be kept under 15 km/h.
Warranty
12 months up to 24 months* * If 1 month and 6 months services have been done by a Crossfire Dealer – warranty is extended to 2 years for vehicles 250cc and up. Please make sure you have proof of services.



ATV Safety Information

NSW Pre purchase check list (if not in NSW please find local state check list prior to purchase)

Quad Bike Safety – What You Need To Know

Quad Bike Training (NSW list of registered ATV organisations. Please look up in own state.)


Download Attachments
